KMPMaps

KMPMaps is a Kotlin Multiplatform library that provides unified map functionality across Android and iOS platforms, leveraging native map implementations (Google Maps on Android and MapKit on iOS) with a simple, composable API.

Features

• Cross-platform Map Component: A unified MapComponent for Android and iOS.
• Markers: Easily add markers with custom titles, snippets, and colors.
• Routes (Polylines): Draw routes on the map with customizable colors and widths.
• Shapes: Draw circles on the map.
• Location Services: Integrated user location display and retrieval.
• Map Controls: Toggle zoom, scroll, rotation, traffic, buildings, and more.
• Utilities: Helper functions for distance calculation and zoom level estimation.

Installation

Add the dependency to your project.

Using Version Catalog

If you are using a version catalog (e.g., libs.versions.toml), add the following:

[versions]
sweetmesoft = "2.0.1"

[libraries]
sweetmesoft-kmpmaps = { module = "com.sweetmesoft.kmpmaps:kmpmaps", version.ref = "sweetmesoft" }

Build Gradle

In your build.gradle.kts (commonMain source set):

implementation(libs.sweetmesoft.kmpmaps)

Platform Configuration

Android

1. API Key: Add your Google Maps API key to your local.properties or directly in AndroidManifest.xml (though local.properties is safer, for this guide we show the manifest meta-data).

   In AndroidManifest.xml:

   <meta-data
       android:name="com.google.android.geo.API_KEY"
       android:value="YOUR_GOOGLE_MAPS_API_KEY" />


2. Permissions: Add location permissions if you intend to use location features.

   <uses-permission android:name="android.permission.ACCESS_FINE_LOCATION" />
   <uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION" />


iOS

1. Permissions: Add location usage descriptions to your Info.plist if you use location features.

   <key>NSLocationWhenInUseUsageDescription</key>
   <string>We need your location to show it on the map.</string>
   <key>NSLocationAlwaysAndWhenInUseUsageDescription</key>
   <string>We need your location to show it on the map.</string>


Usage

Basic Map

Display a simple map centered at a specific location.

import com.sweetmesoft.kmpmaps.MapComponent
import com.sweetmesoft.kmpmaps.controls.Coordinates

@Composable
fun SimpleMap() {
    val center = Coordinates(37.7749, -122.4194) // San Francisco

    MapComponent(
        coordinates = center,
        zoom = 12f
    )
}

Adding Markers

Markers are added via the markers parameter, which takes a list of GeoPosition objects. Each GeoPosition can have a MarkerMap configuration.

import com.sweetmesoft.kmpmaps.controls.GeoPosition
import com.sweetmesoft.kmpmaps.controls.MarkerMap
import androidx.compose.ui.graphics.Color

val markers = listOf(
    GeoPosition(
        coordinates = Coordinates(37.7749, -122.4194),
        markerMap = MarkerMap(
            isVisible = true,
            title = "San Francisco",
            snippet = "A beautiful city",
            iconColor = Color.Red,
            onClick = { position ->
                println("Clicked: ${position.markerMap.title}")
                true // Return true to consume the event
            }
        )
    )
)

MapComponent(
    coordinates = Coordinates(37.7749, -122.4194),
    markers = markers
)

Drawing Routes (Polylines)

Draw lines on the map using RouteMap.

import com.sweetmesoft.kmpmaps.controls.RouteMap

val route = RouteMap(
    points = listOf(
        Coordinates(37.7749, -122.4194),
        Coordinates(34.0522, -118.2437) // LA
    ),
    color = Color.Blue,
    width = 5f
)

MapComponent(
    coordinates = Coordinates(36.0, -120.0),
    zoom = 6f,
    routes = listOf(route)
)

Drawing Circles

Circles are also attached to a GeoPosition via the CircleMap property.

import com.sweetmesoft.kmpmaps.controls.CircleMap

val circlePosition = GeoPosition(
    coordinates = Coordinates(37.7749, -122.4194),
    circleMap = CircleMap(
        radius = 1000.0, // meters
        fillColor = Color.Blue.copy(alpha = 0.3f),
        strokeColor = Color.Blue,
        strokeWidth = 2f
    )
)

MapComponent(
    coordinates = Coordinates(37.7749, -122.4194),
    markers = listOf(circlePosition)
)

User Location

Enable the user’s location display on the map.

MapComponent(
    coordinates = center,
    locationEnabled = true, // Shows the user location dot
    // ...
)

To get the current location programmatically:

import com.sweetmesoft.kmpmaps.getLocation

LaunchedEffect(Unit) {
    try {
        val location = getLocation(updateLocation = true)
        println("User location: ${location.latitude}, ${location.longitude}")
    } catch (e: Exception) {
        println("Error getting location: ${e.message}")
    }
}

API Reference

MapComponent

Parameter	Type	Description	Default
coordinates	Coordinates	Center coordinates of the map.	Required
zoom	Float	Initial zoom level.	1f
zoomEnabled	Boolean	Enable zoom gestures.	true
scrollEnabled	Boolean	Enable scroll gestures.	true
rotateEnabled	Boolean	Enable rotation gestures.	false
locationEnabled	Boolean	Show user location (requires permissions).	false
showPointsOfInterest	Boolean	Show points of interest on the map canvas.	false
markers	List<GeoPosition>	List of positions to display markers or circles.	emptyList()
routes	List<RouteMap>	List of polylines to draw.	emptyList()
showTraffic	Boolean	Show traffic layer.	false
showBuildings	Boolean	Show 3D buildings.	false
showCompass	Boolean	Show compass.	false
onMapClick	(Coordinates) -> Unit	Callback for map click.	{}
onMapLongClick	(Coordinates) -> Unit	Callback for map long click.	{}

Data Classes

Coordinates

• latitude: Double
• longitude: Double

GeoPosition

• coordinates: Coordinates
• address: String
• markerMap: MarkerMap
• circleMap: CircleMap

MarkerMap

• isVisible: Boolean
• title: String
• snippet: String
• iconColor: Color
• onClick: (GeoPosition) -> Boolean
• onInfoWindowClick: (GeoPosition) -> Unit

RouteMap

• points: List<Coordinates>
• color: Color
• width: Float

CircleMap

• radius: Double (in meters)
• fillColor: Color
• strokeColor: Color
• strokeWidth: Float

Utilities

• getLocation(updateLocation: Boolean): Suspend function to get current user location.
• calculateDistance(from: Coordinates, to: Coordinates): Returns distance in meters.
• calculateZoomByRadius(radiusInMeters: Double): Returns appropriate zoom level for a given radius.
• calculateZoomAndCenter(positions: List<Coordinates>): Returns a pair of Float (zoom) and Coordinates (center) to fit all positions.

Requirements

• Android: Min SDK 24, Target SDK 37
• iOS: 12.0+
• Kotlin: 2.4.0
• Compose Multiplatform: 1.11.1

License

This project is licensed under the MIT License.
